Top Quality Cold Storages Machines


Expert in Cold Storage Machinery as Machinery Supplier, Machinery and Processing Equipment, Cold Room, Tube Ice Machine, and Flake Ice Machine in the Philippines.

SCROLL DOWN

Top Quality Cold Storages Machines


Expert in Cold Storage Machinery as Machinery Supplier, Machinery and Processing Equipment, Cold Room, Tube Ice Machine, and Flake Ice Machine in the Philippines.

Tube Ice Machine

tube-ice-side-view

Mainly apply for human consumption such as freeze drinks, mix wines, cool food stuffs, and industrial sphere like chemical cooling, food processing, fisheries, poultry-processing, meat plants etc. Our Tube Ice is hollow, cylindrical ice with external diameter of 22, 29, 32 or 35mm and length of 25 - 50mm. The diameter of the inner hole is usally 5 - 10mm, but can be adjusted according to the ice making time.


tube-ice-machine

Features

Superb Stability and Reliability, long use life

Energy Efficient and Cost Savings Solution for Ice Production

Tube Ice Maker Patented H-M Interactive Control System

Meet HACCP request and Stainless Steel Cutters

Delicate Welding Techniques with X-RAY for No Leakage

Tube Ice Machine Models and Specifications
Model No.Production CapacityIce TemperatureTotal Power KWMachine Size (mm)
MLT-1T1,000-8 Celsius8 KW1400 x 1200 x 1800
MLT-2T2,000-8 Celsius12 KW1600 x 1200 x 2000
MLT-3T3,000-8 Celsius15.5 KW1700 x 1450 x 2000
MLT-5T5,000-8 Celsius23.5 KW1700 x 1700 x 2200
MLT-8T8,000-8 Celsius30 KW2000 x 1750 x 2200
MLT-10T10,000-8 Celsius45 KW2900 x 2280 x 2600
MLT-15T15,000-8 Celsius60 KW3250 x 3000 x 4200
MLT-20T20,000-8 Celsius85 KW3500 x 3350 x 4200
MLT-25T25,000-8 Celsius95 KW3850 x 3650 x 4200
MLT-30T30,000-8 Celsius110 KW4250 x 3650 x 4200
MLT-40T40,000-8 Celsius150 KW5100 x 4700 x 4200
MLT-50T50,000-8 Celsius180 KW6000 x 6000 x 4500

Cold Room

Cold room is the warehouse with suitable moisture and low temperature condition by using cooling equipments, as the location for processing and storage products. It can cast off the climate effect and prolong the storage time of all kinds of products, so as to adjust the market privision, Cold room is used for constant temperature storage in foods, dairy product, meat, aquatic product, birds, fruits, and vegetables, cold drink, flower, green plant, tea, medicine, chemical raw material, and electric instrument.

Structure of Cold Room

Cold room will accomodate our customers with different designs, sizes and thicknesses on the high pressured polyurethane cooler/freezer panels. The special design and custom made sizes and thickness is according to the different temperature requirements. It becomes the best energy saving choice among other selections.

cold-room-first-layer

First Layer

Knurling Aluminum Panel

cold-room-second-layer

SECOND LAYER

Cold Steel Panel: Firm Coat Surface

cold-room-third-layer

Third LAyer

Stainless Steel Panel, Clear and Sanitary, Firm and Durable


Flake Ice Machine

Internally-Scraping Ice Skate that help reduce energy consumption and prevent leakage

Stainless Steel Material, Ensure Best Heat Transfer Efficiency

Prevent Water Leaking at the bottom of drum

Photoelectric switch is directly installed in the bottom of evaporator

Direct Liquid Feeding and Dry Evaporation

Integrated Modular Equipment for Maintenance Conveniency


Why Flake Ice? Its Advantages:

  • Irregular Ice Flakes with Size about 40 x 40 mm and thickness around 1.5-2.5 mm
  • Thin ice can be directly sued for stirring and mixing refrigerated materials
  • No acute edges and corners so it will not damage the surface of the cooled object;
  • Ice Flakes are as cold as below -8 degrees Celsius
  • Large contact area and good mobility to ensure good preservation effect
  • Easy to crush and mold
  • Machine is Small-sized and Convenient for use anytime
Fresh Water Flake Ice Machine Models and Specifications
Model No.Production CapacityIce TemperatureTotal Power KWMachine Size (mm)
MLT-0.5T500-8 Celsius2.7 KW1270 x 1030 x 1810
MLT-1T1,000-8 Celsius4.4 KW1320 x 1280 x 2060
MLT-1.5T1,500-8 Celsius6.2 KW1510 x 1400 x 2350
MLT-2T2,000-8 Celsius7.9 KW1510 x 1400 x 2350
MLT-2.5T2,500-8 Celsius10 KW1510 x 1400 x 2520
MLT-3T3,000-8 Celsius10.7 KW1600 x 1300 x 1220
MLT-5T5,000-8 Celsius17.5 KW1850 x 1450 x 1420
MLT-8T8,000-8 Celsius25 KW2200 x 1800 x 1450
MLT-10T10,000-8 Celsius30 KW2200 x 1800 x 1670
MLT-12T12,000-8 Celsius36 KW2800 x 2100 x 1820
MLT-15T15,000-8 Celsius40 KW3200 x 2100 x 1900
MLT-20T20,000-8 Celsius56 KW3600 x 2200 x 2160
MLT-30T30,000-8 Celsius82 KW3600 x 2200 x 2450
MLT-50T50,000-8 Celsius110 KW3800 x 2600 x 250
Sea Water Flake Ice Machine Models and Specifications
Model No.Production CapacityIce TemperatureTotal Power KWMachine Size (mm)
MLTS-1T1,000-10 Celsius5.5 KW1320 x 980 x 1100
MLTS-2T2,000-10 Celsius12.7 KW1510 x 1100 x 1300
MLTS-3T3,000-10 Celsius20.5 KW1800 x 1450 x 1650
MLTS-5T5,000-10 Celsius28 KW2200 x 1800 x 1500
MLTS-10T10,000-10 Celsius35 KW2500 x 1800 x 1700
